The following images show the References panel when selecting features or the model, respectively: Then, to mirror features or the entire model, select or create the plane that you want to mirror about.Ī feature collector has been added in the References panel, which allows editing and will alert you if features are missing.

To mirror the entire model, select the model name in the model tree.Ĭlick the icon located in the Editing group in the Model tab.

To mirror one or a set of features, select the feature(s) in the model tree or on the model.

You can use one of the following methods to select geometry to mirror:

The Mirror operation in Creo Parametric 5.0 has been enhanced resulting in faster definition or redefinition of the Mirror feature.

In Creo Parametric, you can mirror selected features or the entire model geometry about a planar reference.
